Description
Product Paramenters
|
Model
|
ZWY-60/30L
|
ZWY-80/37L
|
ZWY-100/45L
|
|
Walking speed(Km/h)
|
2
|
2
|
2
|
|
Load capacity(m³/h)
|
60
|
80
|
100
|
|
Rated working pressure (Mpa)
|
16
|
16
|
20
|
|
Max turning angle(°)
|
±73
|
±73
|
±73
|
|
Total motor power（KW）
|
30
|
37
|
45
|
|
Max. size of passage (mm)
|
600*650
|
600*500
|
600×600
|
|
The way of walking
|
Crawler
|
Crawler
|
Crawler
|
|
Dimensions(mm)
|
5400x1500x1650
|
6000x1700x1700
|
6150x1900x1800
|
|
Machine quality (Kg)
|
4900
|
6800
|
8000
|
|
Min turning radius (m)
|
4
|
5.5
|
4
|
|
Digging width (mm)
|
3900
|
3400
|
4200
|
|
Digging height(mm)
|
2700
|
2750
|
3600
|
|
Digging depth(mm)
|
700
|
700
|
700
|
|
Digging distance(mm)
|
1780
|
1550
|
2200
|
|
Unloading height(mm)
|
1600-1900
|
1650
|
1700-2050
|
|
Unloading distance(mm)
|
1500
|
1800
|
1800
|
|
Belt speed(m/s)
|
0.63
|
0.63
|
0.63
|
